DSR - Machine for dry application of granules, frits, powders and sintered glazes

07.04.2021

Machine for dry application of granules, frits, powders and sintered glazes, DSR is characterized by simplicity of use, innovative feeding system and reduced overall dimensions. Thanks to just 650 mm width, DSR can be installed easily and without any mechanical modification on any existing glazing line.
It allows a full-field application with a few grams of material up to covers with high quantities suitable for subsequent lapping, maintaining a constant and uniform coverage on tiles and slabs up to 2200 mm wide.
The machine is composed of a self-supporting structure completely closed to avoid dispersion in the environment and to maintain a constant application over time. The system uses a motorized rubber coated roller controlled by an inverter to manage the extraction and the dosage of the material to be applied, a stainless steel collection tank with an anti-intrusion system, a feed and recycle feeding unit and a dosing hopper with a self-leveling system distribution.
The management is completely automatic, through an electrical control panel with PLC and programming keyboard.
The DSR machine can be equipped with a separated feeding container (model CF) to increase the production autonomy. In case of production with glue printings, before the powder application, the system can be completed with the suction device model CGA, composed by cyclone with anti-waste internal covering, discharge automatic valve and balanced suction pipes. This system can also be equipped with a screening and pneumatic automatic recycle device that brings back the material recovered inside of the DSR machine.

REVERSO

03.03.2021

Reverso is a roller decorating machine for printing and applying engobe to the reverse side of tiles as they proceed along the glazing line. This application prevents contamination due to direct contact between the tile and the ceramic rollers in the kiln during firing.

Incorrect or nonuniform application of these products may result in serious damage, including rapid deterioration of the ceramic rollers, deformation of tile flatness and undesirable accumulation of tiles inside the kiln.

These issues are often timeconsuming and costly to resolve, resulting in severe delays and production losses.

Thanks to the laserengraved silicone roller application system, Reverso ensures perfect and uniform engobe application to the rear face of the tiles with the possibility of controlled application weights. It avoids all product wastage, does not contaminate the tile edges and is able to print logos and other designs.

Available for sizes up to 1800 mm wide, it uses silicone cylinders with lengths from 1020 mm to 2200 mm.

Machine characteristics:

  • independent supporting frame with adjustable feet;
  • device for rapid assembly/disassembly of the engraved silicone roller;
  • independent blade groups with adjustable height, inclination and angle of incidence;
  • registers to adjust contact between the silicone roller and the tiles;
  • invertercontrolled gear motor for regulating the speed of rotation of the roller as the tile advances;
  • automatic management of the rotational speed;
  • automatic printhead ascent/descent device controlled by a photocell for flow control;
  • lower stainless steel tank for excess glaze recovery;
  • feeding group complete with pneumatic pump with pausework management;
  • double blade group feeding device;
  • silicone roller with various mask type special engravings;
  • electrical panel complete with inverter, general controls, encoder, flow control photocell, pump management and onboard plant.

youtu.be/n3iIl6pZOYI

CFI GLOBAL NEWS: THE DSR MACHINE

16.06.2020

What is DSR and how does it work?



CFI Ceramic Forum International, technical-scientific journal for the ceramics industry, presents our machine for the dry application of grits, frits and powders, describing the full operation.



The article is on the front pages, on Global News section.

www.cfi.de/issuebrowser/cfi_2020_5-6/html5/index.html?&locale=ITA
